Volute Center-distance Measuring Machine
Test Items
Center distance
Worm-wheel bearing bore
Worm bearing bore
Worm-wheel bearing bore
Worm bearing bore
Product Features
1.Supports rapid measurement and rapid sorting; inspection cycle＜35s.
2.Palletizing mechanism for loading & unloading, enabling 90-minute unattended operation.
3.Compatible with measurement of multiple-specification housing products via model change-over.
4.Equipped with gantry robot for material handling to realize full automation including loading, measurement, marking and sorting.
2.Palletizing mechanism for loading & unloading, enabling 90-minute unattended operation.
3.Compatible with measurement of multiple-specification housing products via model change-over.
4.Equipped with gantry robot for material handling to realize full automation including loading, measurement, marking and sorting.
