Automatic Piston Measuring Machine
Test Items
Major skirt diameter (3 positions)
Ring-groove root diameter (3 positions)
Pin-bore diameter (4 sections)
Compression height
Note: Rotate to find the maximum value for major skirt diameter
Ring-groove root diameter (3 positions)
Pin-bore diameter (4 sections)
Compression height
Note: Rotate to find the maximum value for major skirt diameter
Product Features
1. Measurement accuracy: ≤1.5 μm
2. Measurement cycle: ≤12 s
3. Optical automatic centering of pin bore before measurement
4. Rotate workpiece to measure maximum outer diameter during measurement
5. Adjustable measuring range with quick changeover capability
2. Measurement cycle: ≤12 s
3. Optical automatic centering of pin bore before measurement
4. Rotate workpiece to measure maximum outer diameter during measurement
5. Adjustable measuring range with quick changeover capability
