axial distance and end‑face run‑out
radial run‑out of internal spline
inner bore diameter, cylindricity and run‑out
outer circle diameter, roundness, cylindricity and run‑out

1.Spline runout is measured via meshing inspection.
2.Connect with customer truss manipulators for automatic on-line measurement.
3.Equipped with constant-temperature air-conditioning and temperature compensation for higher on-line measurement accuracy.
4.Compatible with measurement of multiple specifications of input shafts.
